Machine-made Stainless Steel Sandwich Panel
Machine-made Stainless Steel Sandwich Panels can be customized to different thicknesses and different core materials can be selected.
Stainless steel sandwich panels are very suitable for industries with humid environments or corrosion protection requirements.
|
Product Name: |
Machine-made Stainless Steel Sandwich Panel |
|
Panel Thickness: |
50mm, 75mm, 100mm |
|
Panel Width： |
1000mm, 1200mm |
|
Effective Width: |
950mm, 1150mm |
|
Panel Surface: |
PE, PVDF (fluorocarbon), Al-mg-Mn Alloy Steel, Saltized board, antistatic, Stainless Steel |
|
Panel Surface thickness: |
0.4-0.6mm |
|
Core Material: |
Rock Wool, PU/PUR/PIR, Silicon Rock, Ageless Foam, Magnesium Oxysulfide, Hollow Glass Magnesium, Glass Magnesium Rockwool |
|
Connection Method : |
Tongue-and-groove splicing |
Smooth, seamless surface minimizes dust accumulation and
allows easy sterilization, meeting stringent cleanroom hygiene standards.
2. Superior Thermal & Acoustic InsulationRock wool offers superior sound insulation performance.
PU/PIR cores provide high thermal resistance (low U-value), reducing
energy costs.3. Excellent Fire Resistance
Core materials with different fire protection levels from A1 to B1/B2
4. Superior Dustproof & Antimicrobial Properties
Special coatings or antimicrobial materials inhibit bacterial growth,
making them ideal for medical, electronics, and other sensitive
industries.
5. Modular & Easy InstallationStandardized modular design enables fast assembly, reducing labor
costs and facilitating maintenance.
6. Eco-friendlyThermal/acoustic insulation cores reduce energy consumption, with
recyclable materials aligning with green building practices.
Depending on the core material and surface steel plate composition, these panels provide different functionalities, such as:
Rock wool core panels: Exceptional fire resistance, thermal insulation, and sound absorption.
PU/PIR core panels: Outstanding thermal insulation, helping reduce energy consumption.
Magnesium oxysulfide core panels: High strength and fireproof performance.
